GOLD PLACER MINING

Untitled Document -------------------- -----------------
GOLD CLAIMER, OREGON PIONEER
MINING EQUIPMENT
Good luck!
.
GEOLASER
Gold Placer Mining Equipment by
GEOLASER Company

•

•

•

•

•

Gold Claimer Concentrator
$6,500 - FOB manufacturer
Gold Claimer Concentrator

Zoom & Full Description
 - Water feed valves for trommel and hopper feed control
- Revolving scrubber and trommel with positive chain drive
- Removable oscillating sluice (150 impulses/minute)
- Teel cast iron 3950 G.P.H. water pump
- Variable speed single belt drive for simplicity and reliability
- 100 gallon capacity reserve water storage tank
- Auger style de-watering screw
- 13 GA steel construction made for industrial use
- Sealed steel bearings
- 8'L x 2.5'W x 4.5'H @ 840 lbs.
- Capacity 2 to 8 cubic yards per hour
- Trailer mounted with lights, fenders and 4.80 wheels
- Honda engine

•

•

Gold Claimer, African Model
- Call for prices -

- Same as Gold Claimer Concentrator shown above, but without 100 gallon capacity reserve water storage tank and without de-watering screw
- This unit designed to work for properties with original water supply

•

•

•

•

12-Feet Conveyor
$4,900 - FOB manufacturer
12-Feet Feed Conveyor

- Even feed @ 100 feet per minute
- Chain Drive, 12 inch X 12 foot, 2 ply Rubber Belt
- Honda air cooled engine
- 14 GA Steel Construction
- Trailer Mounted
- Folds down to 9 ft. Long for transportation
- 4 ft. X 4 ft. (3/4 cu. Yd.) Steel Hopper w/belt flashing and feed control
- Rock Grizzly w/ 2" openings
- For use w/ skid loader or other loader
- 12' Long X 4' 7" Wide
- Weight:  900 Lbs
- One Week Delivery

•

•

•

•

•

•

Oregon Pioneer-15 YPH
$20,700 - FOB manufacturer

With hydraulic leveling jacks
$2,500 extra - FOB manufacturer

Oregon Pioneer

- 13HP OHC w/ Electric Start Engine w/ Single Hydraulic Pump
- 15 gallon Reservoir
- 6' Feed Conveyor w/ Self Cleaning Return
- 3 Flow Controls (Trommel, Feed & Discharge)
- Oscillating sluice box 18" wide 6' long (2 each 3' sections)
- Trommel drum 5' long x 2' diameter with 2' high tensile 3/8" screen
- Grizzly 50" long 59" wide 2" bar spacing
- Self supporting discharge conveyor 12" wide 90" long
- Sealed Centric Locking Pillow Block Bearings
- 4 Stabilizing Jacks
- Hydraulic Filter
- DOT Approved Trailer Lights
- Adjustable Tongue Height
- Supply Quick Disconnect
- Clean up Water Supply Connect w/ Valve
- Tandem Axle w/ 205/75/D14 Tires
- Easy Lube Axle w/ Joined Equalizers
- Two-Week Delivery/mfr.time

•

•

•

•

Oregon Pioneer-30 YPH
$38,500 - FOB manufacturer

Oregon Pioneer 30 YPH

- Almost the same as the Pioneer 15 YPH, but twice more capacity


Zoom & Full Description

•

•

•

•

•

•

SLUICE BOX for Oregon Pioneer-15 &
Oregon Pioneer-30 (shown above),
or can be used separately with other processing equipment.
Manufacturer - Geolaser.

SLUICE BOX

 Sluice Box Set:

  • Main box 1/8" Steel 10 feet x 24 inches x 8 inches and 1" lip with bolts and nuts - $600

  • Three each,  3-pound, expanded metal riffles
    (two pieces 2' x 4' and one piece 2' x 2') - $240

  • Four each hold down plates 5 feet x 6 inches - $340

  • Klondike miner moos ⅝ inches x 2 feet x 10 feet - $80

  • One back plate - $60

  • Supporting 3" channel frame under the box not included in the set, but could be manufactured and added separately

  • Complete sets: Steel $1,200, Aluminum $1,400. Cost FOB Nevada Whse


•

Gold Nugget from Alaska.

Good Luck!
